廣泛的加工領域
| 記號 | 螺紋尺寸 | 等級 | 等級 | 導向牙 | 全長 | 螺紋長 | 溝數 | 角徑 | 角下長 | 頭徑 | 種類 |
| 3M0.5R | M3x0.5 | REG | P2 | 5 | 46 | 10 | 3 | 4 | 18 | 2.4 | 1 |
| 3M0.5R+1 | M3x0.5 | REG+1 | P3 | 5 | 46 | 10 | 3 | 4 | 18 | 2.4 | 1 |
| 3M0.5R+2 | M3x0.5 | REG+2 | P4 | 5 | 46 | 10 | 3 | 4 | 18 | 2.4 | 1 |
| 3M0.35R | M3x0.35 | REG | P1 | 5 | 46 | 8 | 3 | 4 | 18 | 2.4 | 1 |
| 3M0.35R+1 | M3x0.35 | REG+1 | P2 | 5 | 46 | 8 | 3 | 4 | 18 | 2.4 | 1 |
| 3.5M0.6R | M3.5x0.6 | REG | P2 | 5 | 48 | 11 | 3 | 4 | 18 | 2.8 | 1 |
| 3.5M0.6R+1 | M3.5x0.6 | REG+1 | P3 | 5 | 48 | 11 | 3 | 4 | 18 | 2.8 | 1 |
| 3.5M0.35R | M3.5x0.35 | REG | P1 | 5 | 48 | 8 | 3 | 4 | 18 | 2.8 | 1 |
| 3.5M0.35R+1 | M3.5x0.35 | REG+1 | P2 | 5 | 48 | 8 | 3 | 4 | 18 | 2.8 | 1 |
| 4M0.7R | M4x0.7 | REG | P2 | 5 | 52 | 12.5 | 3 | 5 | 18 | 3.1 | 1 |
| 4M0.7R+1 | M4x0.7 | REG+1 | P3 | 5 | 52 | 12.5 | 3 | 5 | 18 | 3.1 | 1 |
| 4M0.7R+2 | M4x0.7 | REG+2 | P4 | 5 | 52 | 12.5 | 3 | 5 | 18 | 3.1 | 1 |
| 4M0.5R | M4x0.5 | REG | P2 | 5 | 52 | 10 | 3 | 5 | 18 | 3.1 | 1 |
| 4M0.5R+1 | M4x0.5 | REG+1 | P3 | 5 | 52 | 10 | 3 | 5 | 18 | 3.1 | 1 |
| 4.5M0.75R | M4.5x0.75 | REG | P2 | 5 | 55 | 13.5 | 3 | 5 | 20 | 3.6 | 1 |
| 4.5M0.75R+1 | M4.5x0.75 | REG+1 | P3 | 5 | 55 | 13.5 | 3 | 5 | 20 | 3.6 | 1 |
| 4.5M0.5R | M4.5x0.5 | REG | P2 | 5 | 55 | 10 | 3 | 5 | 20 | 3.6 | 1 |
| 4.5M0.5R+1 | M4.5x0.5 | REG+1 | P3 | 5 | 55 | 10 | 3 | 5 | 20 | 3.6 | 1 |
| 5M0.8R | M5x0.8 | REG | P2 | 5 | 60 | 14.5 | 3 | 5.5 | 25 | 4 | 1 |
| 5M0.8R+1 | M5x0.8 | REG+1 | P3 | 5 | 60 | 14.5 | 3 | 5.5 | 25 | 4 | 1 |
| 5M0.8R+2 | M5x0.8 | REG+2 | P4 | 5 | 60 | 14.5 | 3 | 5.5 | 25 | 4 | 1 |
| 5M0.5R | M5x0.5 | REG | P2 | 5 | 60 | 10 | 3 | 5.5 | 25 | 4 | 1 |
| 5M0.5R+1 | M5x0.5 | REG+1 | P3 | 5 | 60 | 10 | 3 | 5.5 | 25 | 4 | 1 |
| 5.5M0.5R | M5.5x0.5 | REG | P2 | 5 | 60 | 10 | 3 | 5.5 | 26 | 4.4 | 1 |
| 5.5M0.5R+1 | M5.5x0.5 | REG+1 | P3 | 5 | 60 | 10 | 3 | 5.5 | 26 | 4.4 | 1 |
| 6M1R | M6x1 | REG | P2 | 5 | 62 | 17 | 3 | 6 | 28 | 4.8 | 1 |
| 6M1R+1 | M6x1 | REG+1 | P3 | 5 | 62 | 17 | 3 | 6 | 28 | 4.8 | 1 |
| 6M1R+2 | M6x1 | REG+2 | P4 | 5 | 62 | 17 | 3 | 6 | 28 | 4.8 | 1 |
| 6M0.75R | M6x0.75 | REG | P2 | 5 | 62 | 14 | 3 | 6 | 28 | 4.8 | 1 |
| 6M0.75R+1 | M6x0.75 | REG+1 | P3 | 5 | 62 | 14 | 3 | 6 | 28 | 4.8 | 1 |
| 6M0.5R | M6x0.5 | REG | P2 | 5 | 62 | 10 | 3 | 6 | 28 | 4.8 | 1 |
| 6M0.5R+1 | M6x0.5 | REG+1 | P3 | 5 | 62 | 10 | 3 | 6 | 28 | 4.8 | 1 |
| 7M1R | M7x1 | REG | P2 | 5 | 65 | 17 | 3 | 6.2 | 2 | ||
| 7M1R+1 | M7x1 | REG+1 | P3 | 5 | 65 | 17 | 3 | 6.2 | 2 | ||
| 7M0.75R | M7x0.75 | REG | P2 | 5 | 65 | 14 | 3 | 6.2 | 2 | ||
| 7M0.75R+1 | M7x0.75 | REG+1 | P3 | 5 | 65 | 14 | 3 | 6.2 | 2 | ||
| 8M1.25R | M8x1.25 | REG | P3 | 5 | 70 | 22 | 3 | 6.2 | 2 | ||
| 8M1.25R+1 | M8x1.25 | REG+1 | P4 | 5 | 70 | 22 | 3 | 6.2 | 2 | ||
| 8M1.25R+2 | M8x1.25 | REG+2 | P5 | 5 | 70 | 22 | 3 | 6.2 | 2 | ||
| 8M1R | M8x1 | REG | P2 | 5 | 70 | 17 | 3 | 6.2 | 2 | ||
| 8M1R+1 | M8x1 | REG+1 | P3 | 5 | 70 | 17 | 3 | 6.2 | 2 | ||
| 8M0.75R | M8x0.75 | REG | P2 | 5 | 70 | 14 | 3 | 6.2 | 2 | ||
| 8M0.75R+1 | M8x0.75 | REG+1 | P3 | 5 | 70 | 14 | 3 | 6.2 | 2 | ||
| 9M1.25R | M9x1.25 | REG | P3 | 5 | 72 | 22 | 3 | 7 | 2 | ||
| 9M1.25R+1 | M9x1.25 | REG+1 | P4 | 5 | 72 | 22 | 3 | 7 | 2 | ||
| 9M1R | M9x1 | REG | P2 | 5 | 72 | 17 | 3 | 7 | 2 | ||
| 9M1R+1 | M9x1 | REG+1 | P3 | 5 | 72 | 17 | 3 | 7 | 2 | ||
| 9M0.75R | M9x0.75 | REG | P2 | 5 | 72 | 14 | 3 | 7 | 2 | ||
| 9M0.75R+1 | M9x0.75 | REG+1 | P3 | 5 | 72 | 14 | 3 | 7 | 2 | ||
| 10M1.5R | M10x1.5 | REG | P3 | 5 | 75 | 27 | 3 | 7 | 2 | ||
| 10M1.5R+1 | M10x1.5 | REG+1 | P4 | 5 | 75 | 27 | 3 | 7 | 2 | ||
| 10M1.5R+2 | M10x1.5 | REG+2 | P5 | 5 | 75 | 27 | 3 | 7 | 2 | ||
| 10M1.25R | M10x1.25 | REG | P3 | 5 | 75 | 22 | 3 | 7 | 2 | ||
| 10M1.25R+1 | M10x1.25 | REG+1 | P4 | 5 | 75 | 22 | 3 | 7 | 2 | ||
| 10M1R | M10x1 | REG | P2 | 5 | 75 | 17 | 3 | 7 | 2 | ||
| 10M1R+1 | M10x1 | REG+1 | P3 | 5 | 75 | 17 | 3 | 7 | 2 | ||
| 10M0.75R | M10x0.75 | REG | P2 | 5 | 75 | 14 | 3 | 7 | 2 | ||
| 10M0.75R+1 | M10x0.75 | REG+1 | P3 | 5 | 75 | 14 | 3 | 7 | 2 |
| 記號 | 螺紋尺寸 | 等級 | 等級 | 導向牙 | 全長 | 螺紋長 | 溝數 | 角徑 | 角下長 | 頭徑 | 種類 |
| 11M1.5R | M11x1.5 | REG | P3 | 5 | 80 | 27 | 3 | 8 | 2 | ||
| 11M1.5R+1 | M11x1.5 | REG+1 | P4 | 5 | 80 | 27 | 3 | 8 | 2 | ||
| 11M1R | M11x1 | REG | P2 | 5 | 80 | 17 | 3 | 8 | 2 | ||
| 11M1R+1 | M11x1 | REG+1 | P3 | 5 | 80 | 17 | 3 | 8 | 2 | ||
| 11M0.75R | M11x0.75 | REG | P2 | 5 | 80 | 14 | 3 | 8 | 2 | ||
| 11M0.75R+1 | M11x0.75 | REG+1 | P3 | 5 | 80 | 14 | 3 | 8 | 2 | ||
| 12M1.75R | M12x1.75 | REG | P4 | 5 | 82 | 32 | 3 | 8.5 | 2 | ||
| 12M1.75R+1 | M12x1.75 | REG+1 | P5 | 5 | 82 | 32 | 3 | 8.5 | 2 | ||
| 12M1.75R+2 | M12x1.75 | REG+2 | P6 | 5 | 82 | 32 | 3 | 8.5 | 2 | ||
| 12M1.5R | M12x1.5 | REG | P3 | 5 | 82 | 28 | 3 | 8.5 | 2 | ||
| 12M1.5R+1 | M12x1.5 | REG+1 | P4 | 5 | 82 | 28 | 3 | 8.5 | 2 | ||
| 12M1.25R | M12x1.25 | REG | P3 | 5 | 82 | 23 | 3 | 8.5 | 2 | ||
| 12M1.25R+1 | M12x1.25 | REG+1 | P4 | 5 | 82 | 23 | 3 | 8.5 | 2 | ||
| 12M1R | M12x1 | REG | P2 | 5 | 82 | 19 | 3 | 8.5 | 2 | ||
| 12M1R+1 | M12x1 | REG+1 | P3 | 5 | 82 | 19 | 3 | 8.5 | 2 | ||
| 14M2R | M14x2 | REG | P4 | 5 | 88 | 32 | 3 | 10.5 | 2 | ||
| 14M2R+1 | M14x2 | REG+1 | P5 | 5 | 88 | 32 | 3 | 10.5 | 2 | ||
| 14M1.5R | M14x1.5 | REG | P3 | 5 | 88 | 28 | 3 | 10.5 | 2 | ||
| 14M1.5R+1 | M14x1.5 | REG+1 | P4 | 5 | 88 | 28 | 3 | 10.5 | 2 | ||
| 14M1.25R | M14x1.25 | REG | P3 | 5 | 88 | 23 | 3 | 10.5 | 2 | ||
| 14M1R | M14x1 | REG | P2 | 5 | 88 | 19 | 3 | 10.5 | 2 | ||
| 16M2R | M16x2 | REG | P4 | 5 | 95 | 32 | 3 | 12.5 | 2 | ||
| 16M2R+1 | M16x2 | REG+1 | P5 | 5 | 95 | 32 | 3 | 12.5 | 2 | ||
| 16M1.5R | M16x1.5 | REG | P3 | 5 | 95 | 28 | 3 | 12.5 | 2 | ||
| 16M1.5R+1 | M16x1.5 | REG+1 | P4 | 5 | 95 | 28 | 3 | 12.5 | 2 | ||
| 16M1R | M16x1 | REG | P2 | 5 | 95 | 19 | 3 | 12.5 | 2 | ||
| 18M2.5R | M18x2.5 | REG | P4 | 5 | 100 | 37.5 | 3 | 14 | 2 | ||
| 18M2.5R+1 | M18x2.5 | REG+1 | P5 | 5 | 100 | 37.5 | 3 | 14 | 2 | ||
| 18M2R | M18x2 | REG | P4 | 5 | 100 | 32 | 3 | 14 | 2 | ||
| 18M1.5R | M18x1.5 | REG | P3 | 5 | 100 | 28 | 3 | 14 | 2 | ||
| 18M1.5R+1 | M18x1.5 | REG+1 | P4 | 5 | 100 | 28 | 3 | 14 | 2 | ||
| 18M1R | M18x1 | REG | P2 | 5 | 100 | 19 | 3 | 14 | 2 | ||
| 20M2.5R | M20x2.5 | REG | P4 | 5 | 105 | 37.5 | 3 | 15 | 2 | ||
| 20M2.5R+1 | M20x2.5 | REG+1 | P5 | 5 | 105 | 37.5 | 3 | 15 | 2 | ||
| 20M2R | M20x2 | REG | P4 | 5 | 105 | 32 | 3 | 15 | 2 | ||
| 20M1.5R | M20x1.5 | REG | P3 | 5 | 105 | 28 | 3 | 15 | 2 | ||
| 20M1.5R+1 | M20x1.5 | REG+1 | P4 | 5 | 105 | 28 | 3 | 15 | 2 | ||
| 20M1R | M20x1 | REG | P2 | 5 | 105 | 19 | 3 | 15 | 2 | ||
| 22M2.5R | M22x2.5 | REG | P4 | 5 | 115 | 37.5 | 3 | 17 | 2 | ||
| 22M2.5R+1 | M22x2.5 | REG+1 | P5 | 5 | 115 | 37.5 | 3 | 17 | 2 | ||
| 22M2R | M22x2 | REG | P4 | 5 | 115 | 32 | 3 | 17 | 2 | ||
| 22M1.5R | M22x1.5 | REG | P3 | 5 | 115 | 28 | 3 | 17 | 2 | ||
| 22M1.5R+1 | M22x1.5 | REG+1 | P4 | 5 | 115 | 28 | 3 | 17 | 2 | ||
| 22M1R | M22x1 | REG | P2 | 5 | 115 | 19 | 3 | 17 | 2 | ||
| 24M3R | M24x3 | REG | P4 | 5 | 120 | 45 | 3 | 19 | 2 | ||
| 24M3R+1 | M24x3 | REG+1 | P5 | 5 | 120 | 45 | 3 | 19 | 2 | ||
| 24M2R | M24x2 | REG | P4 | 5 | 120 | 33 | 3 | 19 | 2 | ||
| 24M1.5R | M24x1.5 | REG | P3 | 5 | 120 | 31 | 3 | 19 | 2 | ||
| 24M1.5R+1 | M24x1.5 | REG+1 | P4 | 5 | 120 | 31 | 3 | 19 | 2 | ||
| 24M1R | M24x1 | REG | P2 | 5 | 120 | 20 | 3 | 19 | 2 |
